Dynamic experimental study on rock meso-cracks growth by digital image processing technique

来源期刊：中南大学学报(英文版)2008年第z2期

论文作者：朱珍德 倪骁慧 王伟 李双蓓 赵杰 武沂泉

文章页码：114 - 120

Key words：marble； rock failure process； digital image processing； growth of meso-crack； dynamic observation； experimental study

Abstract: A new meso-mechanical testing scheme based on SEM was developed to carry out the experiment of microfracturing process of rocks. The microfracturing process of the pre-crack marble sample on surrounding rock in the immerged Long-big tunnel in Jinping Cascade II Hydropower Station under uniaxial compression was recorded by using the testing scheme. According to the stereology theory, the propagation and coalescent of cracks at meso-scale were quantitatively investigated with digital technology. Therefore, the basic geometric information of rock microcracks such as area, angle, length, width, perimeter, was obtained from binary images after segmentation. The failure mechanism of specimen under uniaxial compression with the quantitative information was studied from macro and microscopic point of view. The results show that the image of microfracturing process of the specimen can be observed and recorded digitally. During the damage of the specimen, the distribution of microcracks in the specimen is still subjected to exponential distribution with some microcracks concentrated in certain regions. Finally, the change law of the fractal dimension of the local element in marble sample under different external load conditions is obtained by means of the statistical calculation of the fractal dimension.
