Crystal structure and electrochemical behaviors of Pt/mischmetal film electrodes

来源期刊：中国有色金属学报(英文版)2003年第1期

论文作者：张文魁 杨晓光 马淳安 王云刚 余厉阳

文章页码：20 - 24

Key words：rare earth films; electrochemical behaviors; cyclic voltamagraph

Abstract: The Ml(La-rich mischmetal) films with a thin Pt layer on the substrate of chemically coarsen ITO glass or silicon slices were prepared by magnetic sputtering technique. The crystal structure and surface morphology of the films were investigated by X-ray diffraction(XRD) analysis and atomic force microscopy(AFM), respectively. The electrochemical hydridation/dehydridation behaviors of the films in KOH solution were studied by using cyclic voltammagraph and electrochemical impedance spectrum(EIS) as well. The AFM results show that the Pt cover layer on the Ml films is of island structure with a grain of 150-200nm in size. The presence of a thin Pt layer can provide sufficient high electrocatalytic activity for the electrochemical charge-transfer reaction. The electrochemical reduction and oxidation reaction occur on the Pt layer, and the diffusion of H into the Ml film is the rate-controlled step. The Pt coatings also act as protective layers, preventing oxidation and/or poisoning of the underlying Ml films in air.
